Design Features
- Available in standard duty type with 25° contact angle and maximum capacity type with filling slot and 32° contact angle
- Available with pressed steel and polyamide resin cages
- Available as open bearings or with contact seal and non-contact shield options
- Radial internal clearances C2, C-normal, C3 and C4
- Dimension series 32 and 33
- Available for bore diameters from 10 to 90 mm
Operating Benefits
- Compact alternative to a matched pair of single row bearings
- High combined load capacity
- High rigidity
Fields of Application including
- Electric motors
- Fans and blowers
- Pumps and compressors
